Damper
RockShox, Deluxe Select Plus, Air, 65.0 mm
Frame Family
Haibike, SDURO AllMtn 7.0+, Aluminium 6061, Thru-axle M12 (1.75) x 148mm, Disc brake Post Mount, Travel= 150 mm
Fork
RockShox, Yari RC, Air, Travel= 160 mm, Aluschaft 1 1/8 - 1 1/2'''' tapered, 15 x 110mm thru-axle Boost
Rear Derailleur
Sram, NX Eagle
Shift Lever
Sram, NX Eagle, Trigger switch, 12 speed
Sprocket
Sram, Eagle PG1210, 11 - 50 teeth
Bottom Bracket
integrated in the motor
Crank Arm
Haibike Components, The Crank ++, Aluminium
Chain
Sram, NX Eagle
Chain Guide
Haibike aluminium/Nylon directmount
Chainring
Sram, 38 teeth
Brake Lever
Shimano, MT501, Aluminium
Brake Disc (Front)
Shimano, RT64 203
Brake (Front)
Shimano, MT520, 203 mm, 4-piston disc brake
Brake Disc (Rear)
Shimano, RT64 180
Brake (Rear)
Shimano, MT520, 180 mm, 4-piston disc brake
Tyre (Rear, If Different)
Maxxis, Minion DHR II , 71-584, 27.5" x 2.80"
Tube
Presta valve
Tyre
Maxxis, Minion DHF, 71-584, 27.5" x 2.80"
Rim (Rear, If Different)
Rodi, Tryp 35, with eyelets, hollow rim, Aluminium
Rim
Rodi, Tryp 35, with eyelets, hollow rim, Aluminium
Front Wheel Hub
Haibike Components, TheHub ++, 6-bolt standard
Rear Wheel Hub
Haibike Components, 6-bolt standard
Spokes
Sapim, Leader, black
Handlebar
Haibike Components, TheBar ++, 780 mm
Grips
Haibike, MTB grips
Stem
Haibike Components, TheStem 2, A-head, Bar bore: 31.8 mm
Headset
Feimin, A-Head Tapered, Aluminium, cartridge bearing
Saddle
Haibike Components, TheSaddle
Seat Post
XLC, AllMtn, Remote, Telescope, 31.6 mm
Pedals
Freeridepedal, Aluminium, mit Reflektor
Clamping Ring
Internal hexagon, 34.9 mm
Engine
Yamaha, PW-X2, 250 W, 80 Nm, 25 km/h
Weight (Kg)
23.6 kg
Permitted Total Weight
120.0 kg
Battery
Yamaha, Lithium Ion, 500 Wh
