Haibike Lyke 10 Electric MTB Carbon Brown 2023

Season:2023

Brand:Haibike

Code:HMPP1BRN

For those who like it light and fast: The Lyke 10, of our new Light eMTB line, convinces with low weight and maximum ePerformance on the trail. The brand new ultra-light Fazua Ride60 motor saves weight and provides just the right support on the mountain. This is where you also benefit from the weight-optimized carbon frame with closed downtube and new kinematics. Due to the innovative placement of the motor in the seat tube, the center of gravity is directly above the bottom bracket, which also provides improved handling. Reliable Shimano shifting and braking components, and 140mm Fox Float suspension specification offer you carefree riding pleasure. The Lyke 10 is the ideal partner for riders who are looking for extra support and at the same time an agile eMTB.

Technical Information

- ENGINE
  Fazua, Ride60, 250W, 60 Nm
- DISPLAY
  Fazua, Straight bar Ring control
- BATTERY
  Fazua, Energy InTube, 430 Wh
- FRAME FAMILY
  Haibike, Lyke, Carbon
- FORK
  RockShox, Lyrik Select, Air, travel= 140 mm, Aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 110mm thru-axle Boost
- DAMPER
  RockShox, Deluxe Select Plus, Air
- CRANK ARM
  Rotor, E-Kapic, Aluminium
- BRAKE (FRONT)
  Shimano, M6120, Hydraulic disc brakes
- BRAKE (REAR)
  Shimano, M6120, Hydraulic disc brakes
- TUBE
  Presta valve
- RIM
  WTB, ST i30 TCS, Double Wall
- CLAMPING RING
  Internal hexagon, 34.9 mm
- REAR DERAILLEUR
  Sram, NX Eagle
- SHIFT LEVER
  Sram, SX Eagle
- BOTTOM BRACKET
  integrated in the motor
- SPROCKET
  Sram, PG1210 Eagle, 11 - 50 teeth
- CHAIN
  Sram, SX Eagle
- CHAINRING
  Rotor, Aluminium, 32 teeth
- CHAIN GUIDE
  Nylon directmount
- BRAKE LEVER
  Shimano, Deore M6100, Aluminium,
- BRAKE DISC (FRONT)
  Shimano, RT EM64LEC, 203 mm
- BRAKE DISC (REAR)
  Shimano, RT-EM600MEC, 180 mm
- TYRE
  Schwalbe, Wicked Will Evo Super Ground, 29" x 2.4"
- FRONT WHEEL HUB
  Alu, Thru Axle
- REAR WHEEL HUB
  Alu, Thru Axle
- SPOKES
  Sapim, Race, Black
- HANDLEBAR
  XLC, FlowBy, 780 mm
- GRIPS
  Haibike, MTB grips
- STEM
  XLC, FlowBy, A-head, 31.8 mm
- HEADSET
  Acros, BlockLock, Aluminium
- SADDLE
  Selle Italia, Model X
- SEAT POST
  Dropper-Post Remote, Aluminium, Telescope, 31.6 mm
- PEDALS
  Freeridepedal, Aluminium, with Reflector
- PERMITTED TOTAL WEIGHT
  120.0 kg
- TYRE (REAR)
  Schwalbe, Wicked Will Evo Super Trail, 29" x 2.4"

Sizing Information

FRAME SIZE (I.E. S, M, ...)	S	M	L	XL
AFRAME HEIGHT (CM)	41.0 cm	44.0 cm	47.0 cm	50.0 cm
BSEAT TUBE ANGLE	74.0 degrees	74.0 degrees	74.0 degrees	74.0 degrees
CSEAT TUBE OFFSET (MM)	36.0 mm	36.0 mm	36.0 mm	36.0 mm
DSEAT ANGLE	77.3 degrees	77.3 degrees	77.3 degrees	77.3 degrees
EHEAD TUBE LENGTH	110.0 mm	120.0 mm	130.0 mm	140.0 mm
FHEAD TUBE ANGLE (DEGREES)	65.0 degrees	65.0 degrees	65.0 degrees	65.0 degrees
GTOP TUBE HORIZONTAL	562.0 mm	592.0 mm	622.0 mm	652.0 mm
HCHAIN STAY LENGTH	450.0 mm	450.0 mm	450.0 mm	450.0 mm
IBOTTOM BRACKET DROP	-25.0 mm	-25.0 mm	-25.0 mm	-25.0 mm
JWHEELBASE	1195.0 mm	1227.0 mm	1259.0 mm	1290.0 mm
KSTACK	611.0 mm	620.0 mm	629.0 mm	638.0 mm
LREACH	424.0 mm	452.0 mm	479.0 mm	506.0 mm
