FrameAlloy Frame / Virtual 4 link kinematic VLK27.5" and 29" compatible / geo adj. / Boost 148x12mm140mm travel / Bosch Gen4 / Integr. removable BatteryTapered Headtube E2, Central Kickstand MountRange Booster Ready
TravelFront: 140mm / Rear: 140mm
ForkMarzocchi Z2 Air / eMTB+Rail 3 / 3-Modes / 15x110mm QR axle / tapered steerer44mm offset / Reb. Adj. / Lockout / 140mm travel
Rear ShockX-Fusion NUDE TrunnionSCOTT custom w. travel / geo adj.3 modes: Lockout-Traction Control-DescendReb. Adj.Travel 140-90-Lockout / 185x50mm
Remote SystemSCOTT TwinLoc 2 TechnologySuspension & Dropper Remote3 modes
Drive UnitBosch Performance CXEU: 25kmh / INT: 20mph
BatteryPowerTube 625Wh
DisplayBosch Purion
Charger4A Charger
Rear DerailleurSRAM NX Eagle / 12 Speed
ShiftersSRAM SX Eagle Single Click
CranksetFSA CK-320 / 165mm / 34T
ChainringSRAM Eagle 34T DM / Steel
ChainSRAM SX Eagle
CassetteSRAM PG1210 / 11-50 T
BrakesSRAM DB8 4 Piston Disc
RotorCenterline CL Rotors 200mm F&R
HandlebarSyncros Hixon 2.0 Rise / Alloy 6061D.B.20mm rise / 8° / 760mmSyncros Comfort lock-on grips
H'stemSyncros FL2.0 / 6061 AlloyL-Shape Spacer & Top Cap / 31.8mm / 6° / 1 1/8"
SeatpostSyncros Duncan Dropper Post 2.531.6mm / S size 100mm / M size 125mm / L size 150mm / XL size 170mm
SeatSyncros Capilano
HeadsetSyncros ER2.0 Press Fit E2 / Tapered 1.5"-1 1/8"OD 52/62mm / ID 44/56mm
Hub (Front)Formula CL-811 / 15x110mm
Hub (Rear)Formula CL-148S / Boost 148x12mm
SpokesStainless Black
RimsSyncros MD30 / 32H / 30mm / Pin JointTubeless ready
Front TireMaxxis Rekon / 29x2.6" / 60TPI Wire BeadEXODual
Rear TireMaxxis Rekon / 29x2.6" / 60TPI Wire BeadEXODual
LightsBosch Light Cable pre-installed F&R
Approx weight in KG24.3 (with tubes)
Approx weight in LBS53.57 (with tubes)
Max. System Weight128kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
