FRAME
Alloy Frame / Virtual 4 link kinematic VLK, 27.5" and 29" compatible / geo adj. / Boost 148x12mm, 150mm travel / Bosch Gen4 / Integr. removable Battery, Tapered Headtube E2/Forkstop, Central Kickstand Mount, Range Booster Ready
TRAVEL
Front: 160mm / Rear: 150mm
FORK
RockShox 35 Silver TK Air15x110mm QR axle / Tapered Steerer, Reb. Adj. / 2 Modes / Lockout / 160mm travel / E-Bike
REAR SHOCK
X-Fusion NUDE Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Reb. Adj., Travel 150-100-Lockout / 185x55mm
REMOTE SYSTEM
SCOTT TwinLoc Suspension System, 3 modes front and rear / integ. Grip clamp
DRIVE UNIT
Bosch Performance CX, EU: 25kmh / INT: 20mph
BATTERY
PowerTube 625Wh
DISPLAY
Bosch Purion
CHARGER
4A Charger
REAR DERAILLEUR
SRAM NX Eagle / 12 Speed
SHIFTERS
SRAM SX Eagle Single Click
CRANKSET
FSA CK-745 165mm / 34T
CHAIN
GUIDESCOTT Custom
CHAINRING
SRAM Eagle 34T DM / Steel
CHAIN
SRAM SX Eagle
CASSETTE
SRAM PG1210 / 11-50 T
BRAKES
Shimano BR-MT520 4 Piston
ROTOR
Front: SM-RT64 CL 203mm / Rear: RT-EM600 CL 203mm
HANDLEBAR
Syncros Hixon 2.0 / Alloy 6061D.B., 12mm rise / 9° / 780mm, Syncros Pro lock-on grips
H'STEM
Syncros FL2.0 / 6061 Alloy, L-Shape Spacer & Top Cap / 31.8mm / 6° / 1 1/8"
SEATPOST
Syncros Duncan Dropper Post 2.5 31.6mm / S size 100mm / M size 125mm / L size 150mm / XL size 170mm
SEAT
Syncros Tofino 2.5 Regular
HEADSET
Acros Blocklock / Tapered 1.5"-1 1/8", OD 52/62mm / ID 44/56mm
HUB (FRONT)
Formula CL-811 / 15x110mm
HUB (REAR)
Formula CL-148S / Boost 148x12mm
SPOKES
Stainless Black
RIMS
Syncros MD30 / 32H / 30mm / Pin Joint, Tubeless ready
FRONT TIRE
Schwalbe MagicMary 29x2.6", Snake Skin / TL-Easy / SuperTrail / Addix Soft
REAR TIRE
Schwalbe Hans Dampf 29x2.6", Snake Skin / TL-Easy / SuperTrail / Addix Speedgrip
LIGHTS
Bosch Light Cable pre-installed F&R
APPROX WEIGHTS IN KG
24.7
APPROX WEIGHTS IN LBS
54.45
MAX. SYSTEM WEIGHT
128 kg
