Frame Family
Haibike, SDURO Cross/Trekking, Aluminium 6061
Fork
SR Suntour, XCM ATB HLO, Lockout, Steel spring, Travel = 63 mm, Steel steerer tube 1 1/8", Quick release 100mm
Handlebar
Haibike Components, 720 mm
Grips
XLC, Comfort bo3
Stem
Haibike Components, The A-head
Headset
Feimin, A-Head Tapered, Ball bearing
Saddle
Haibike Components,
Seat Post
Haibike Components, Aluminium, Patent, 31.6 mm
Pedals
VP, E461, Aluminium, with Reflector
Crank Arm
Haibike Components, Aluminium
Rear Derailleur
Shimano, Deore M4120
Shift Lever
Shimano, Deore M4100, Trigger switch, 10 Speed
Brake Lever
Shimano, MT200
Bottom Bracket
Integrated in the motor
Sprocket
Shimano, CSM4100, 11 - 42 teeth
Chain
KMC, X10
Chainring
Steel, 38 teeth
Brake (Front)
Shimano, MT200, 180 mm, 2-piston disc brake
Brake (Rear)
Shimano, MT200, 160 mm, 2-piston disc brake
Rim
Rodi, Tryp 35, with eyelets, hollow rim, Aluminium
Wheel Hubs
Shimano, M3050, Centerlock
Tyre
Schwalbe, Super Moto X , 62-584, 27.5" x 2.4"
Headlight
Haibike, Skybeamer 150, 50 lm
Rear Light
AXA, Blueline
Dynamo
Via system battery
Engine
Yamaha, PW-ST System, 250W, 70 Nm, 25 km/h
Display
Yamaha, Side Switch, 1.7" LCD, 7 functions
Battery
Yamaha, InTube, 500 Wh
