FRAME
Ransom Carbon / IMP Technology / HMX Main Frame, BB92 / Alloy SL 6011 swingarm, VLK Virtual 4 Link kinematic, 27.5" (2.6 & 2.8) and 29" (2.4 & 2.6) tire compatible with Geo-BB adj. SW dropouts for Boost 12x148mm, TBC Trunnion box construction
FORK
FOX 38 Float Performance Elite Grip 2 Air, HSC - LSC - HSR- LSR adjustable / Kabolt 15x110mm axle, 44mm offset / tapered steerer, 170mm travel
REAR SHOCK
FOX NUDE TR EVOL Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, custom Ramp Adjust with linear and progressive setting, DPS / Reb. Adj., Travel 170-120-Lockout / 205X65mm
REMOTE SYSTEM
TracLoc Technology, Rear Suspension & Dropper Remote, 3 Rear Suspension modes
REAR DERAILLEUR
SRAM GX Eagle 12 Speed
SHIFTERS
SRAM GX Eagle Trigger
CRANKSET
SRAM GX Eagle DUB Boost, 32T
CHAINGUIDE
SCOTT Chainguide
BB-SET
SRAM DUB PF integrated / shell 41x92mm
CHAIN
SRAM CN GX Eagle
CASSETTE
SRAM GX / XG1275 / 10-52 T
BRAKES
Shimano XT M8120 4 Piston Disc
ROTOR
Shimano SM-RT76 / 6 Bolt / 203/F and 180/R
HANDLEBAR
Syncros Hixon 1.5 Rise / Alloy 20140D.B., 20mm rise / 8° / 780mm, Syncros Pro lock-on grips
H'STEM
Syncros XM1.5 / Alloy 6061, integrated Spacer & Top Cap / 31.8mm / 0° / 1 1/8"
SEATPOST
FOX Transfer Performance Elite Dropper Post, 31.6mm / S 125mm / M 150mm / L & XL 175mm
SEAT
Syncros Kaslo 1.5, Titanium Rails
HEADSET
Syncros Pro Press Fit E2 / Tapered 1.5"-1 1/8", OD 50/62mm / ID 44/56mm
WHEELSET
Syncros Revelstoke 2.0 6 Bolt, F: 15x110mm, R: 12x148mm Boost, 30mm Tubeless ready rim 28H / XD Driver, Syncros Axle w/Removable Lever with Tool
FRONT TIRE
Maxxis Assegai / 2.5" / 60TPI Foldable / EXO+ / TR / 3C Maxx Gripp
REAR TIRE
Maxxis Dissector / 2.4" / 120TPI Foldable / EXO+/ TR / 3C Maxx Terra
EXTRAS
Syncros Trail Fender 2 36/38
APPROX WEIGHTS IN KG
14.4 (with tubes)
APPROX WEIGHTS IN LBS
31.75 (with tubes)
MAX. SYSTEM WEIGHT
128kg
