Frame
Genius Carbon HMF Mainframe with Alloy 6061 Swingarm, Integrated Suspension Technology, Virtual 4 Link kinematic / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
Fork
Ohlins RXF36 m.2 Air, TTX-Technology HSC LSC LSR adjustable / 15x110mm Axle, 44mm offset / tapered steerer, 160mm travel
Rear Shock
FOX FLOAT X NUDE PE EVOL Piggy Back Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Climb-Traction Control-Descend, Custom large Air volume / Comp & Reb. Adj., Travel 150-100-Climb / T185X55mm
Remote System
TracLoc Technology, Rear Suspension & Dropper Remote, 3 Rear Suspension modes
Rear Derailleur
SRAM GX Eagle AXS 12 Speed, Wireless Electronic Shift System
Shifters
SRAM GX Eagle AXS Rocker Controller
Crankset
SRAM GX Eagle DUB, 55mm CL / 32T
BB-Set
SRAM DUB PF 92 MTB Wide / shell 41x92mm
Chain
SRAM CN GX Eagle
Cassette
SRAM XG1275 / 10-52 T
Brakes
Shimano XT M8120 4 Piston Disc
Rotor
Shimano SM-RT76 / 6 Bolt / 203/F and 180/R
Handlebar
Syncros Hixon iC Carbon, Size S & M 15mm rise / Size L & XL 25mm rise, back sweep 8° / 780mm, Syncros Endurance lock-on grips
Seatpost
Syncros Duncan Dropper Post 1.5, 31.6mm / S size 140mm / M size 160mm, L size 170mm / XL size 200mm
Wheelset
Syncros Revelstoke 2.0 6 Bolt, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready rim 28H / XD Driver, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools
Front Tire
Maxxis Minion DHF / 120TPI Foldable, Tubeless Ready / EXO 3C maxxTerra
Rear Tire
Maxxis Dissector / 60TPI Foldable, Tubeless Ready / EXO 3C maxxTerra
Extras
SRAM AXS Powerpack, Syncros Fork Fender
Approx weights in KG
14.4 (Tubeless setup)
Approx weights in LBS
31.75 (Tubeless setup)
Max. System Weight
128kg
