Frame
SPARK Alloy SL 6011, Integrated Suspension Technology, Flex Pivot / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
Fork
RockShox Judy Silver TK Solo Air, 15x110mm QR axle / 42mm offset / Tapered Steerer, 2-Modes / Reb. Adj. / Lockout / 130mm travel
Rear Shock
X-Fusion NUDE 5 RLX Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Reb. Adj., Travel 120-80-Lockout / T165X45mm
Remote System
SCOTT TwinLoc 2 Technology, Suspension & Dropper Remote, 3 Suspension modes
Rear Derailleur
Shimano XT RD-M8100 SGS, Shadow Plus / 12 Speed
Shifters
Shimano Deore SL-M6100-R / Rapidfire Plus
Crankset
Shimano FC-MT512-1, 55mm CL / 30T
Bb-Set
Shimano BB-MT500 / shell 41x92mm
Chain
KMC X12
Cassette
Shimano Deore CS-M6100-12 / 10-51 T
Brakes
Shimano MT501 Disc
Rotor
Shimano SM-RT54 CL / F&R 180mm
Handlebar
Syncros Fraser 2.0 DC Alloy 6061 D.B., Mini Rise / back sweep 8° / 740mm, Syncros Performance XC lock-on grips
Stem
Syncros DC 3.0, Syncros Cable Integration System, 0° rise / 6061 Alloy / 31.8mm / 1 1/8"
Seatpost
Syncros Duncan Dropper Post 2.5, 31.6mm / S size 100mm / M size 125mm / L size 150mm
Seat
Syncros Savona 2.5 V-Concept
Headset
Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
Hub (Front)
Formula CL-811 / 15x110mm
Hub (Rear)
Formula CL-3248M / 12x148mm / Micro Spline
Spokes
Stainless Black 15G / 1.8mm
Rims
Syncros X-30SE / 32H / 30mm
Front Tire
Schwalbe Wicked Will / 29x2.4", Performance / TLR / Foldable / Addix
Rear Tire
Schwalbe Wicked Will / 29x2.4", Performance / TLR / Foldable / Addix
Approx Weights In Kg
14.95 (Tubeless setup)
Approx Weights In Lbs
32.96 (Tubeless setup)
Max. System Weight
128kg
