Frame
Spark Carbon HMF Mainframe with Alloy 6011 Swingarm, Integrated Suspension Technology, Flex Pivot / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
Fork
FOX 34 Float Performance Air Grip, 3-Modes / Kabolt 15x110mm axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 130mm travel
Rear Shock
FOX NUDE 5T EVOL Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Custom large air volume / DPS / Reb. Adj., Travel 120-80-Lockout / T165X45mm
Remote System
SCOTT TwinLoc 2 Technology, Suspension & Dropper Remote, 3 Suspension modes
Rear Derailleurs
SRAM GX Eagle AXS 12 Speed, Wireless Electronic Shift System
Shifters
SRAM GX Eagle AXS Rocker Controller
Crankset
SRAM GX Eagle DUB, 55mm CL / 30T
Bb-Set
SRAM DUB PF 92 MTB Wide / shell 41x92mm
Chain
SRAM CN GX Eagle
Cassette
SRAM XG1275 / 10-52 T
Brakes
SRAM DB8 4 Piston Disc
Rotor
SRAM HS2 Rotos / 6 Bolt / F&R 180mm
Handlebar
Syncros Fraser 1.5 DC Alloy 7075 D.B., Mini Rise / back sweep 8° / 740mm, Syncros Performance XC lock-on grips
Stem
Syncros DC 1.5, Syncros Cable Integration System, 0° rise / 7050 Alloy / 31.8mm / 1 1/8"
Seatpost
Syncros Duncan Dropper Post 1.5, 31.6mm / S/M size 125mm / L size 140mm
Seat
Syncros Savona 2.0 V-Concept, CrMo rails
Headset
Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
Wheelset
Syncros Silverton 2.5-30 6 Bolt, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready rim 28H / XD Driver, Syncros Axle w/Removable Lever with 6mm Allen, T30 and T25 Tools
Front Tire
Schwalbe Wicked Will 29x2.4" EVO, Super Race / TLE / 67EPI / Addix Speed Soft
Rear Tire
Schwalbe Wicked Will 29x2.4" EVO, Super Race / TLE / 67EPI / Addix Speed Grip
Extras
Syncros Fork Fender
Approx Weights in kg
12.9 (Tubeless setup)
Approx Weights in lbs
28.44 (Tubeless setup)
Max. System Weight
128kg
