FrameGenius Alloy 6061Integrated suspension technologyVirtual 4 link kinematic / adjustable head angleSyncros cable integration systemBB92 / UDH interface / 12x148mm with 55mm Chainline
ForkX-Fusion Sweep Boost RC 27.5"tapered / 110x15mm / Air kids tune150mm travel
Rear ShockX-Fusion 02Pro R Trunnion KIDSvertical valve position / rebound adjuster / Kids tune150mm travel / 185x55mm
Rear DerailleurSRAM SX Eagle 12 Speed
ShiftersSRAM NX Eagle Trigger / MMX
CranksetSRAM X1 1000 CL55 Eagle DUB / 155mm / 30T
ChainguideSCOTT custom
BB-SetSRAM DUB PF 92 MTB Wide / shell 41x92mm
ChainSRAM CN SX Eagle
CassetteSRAM SX Eagle / PG-1210 / 11-50T
Brake LeversShimano BL-MT501
BrakesShimano BR-MT500
RotorShimano SM-RT30 CL / F:203 R:180
HandlebarSyncros Hixon 2.0 Alloy 6061 D.B.12mm Rise / back sweep 9° / 740mmSyncros Performance XC lock-on grips
H'stemLEADTEC / 40mm / +/-7°31.8mm clamp
SeatpostSyncros Dropper Ducan Remote31.6mm / 80mm / Kid centric custom tune / Remote Lever I-Spec II
SeatSyncros Future Pro
HeadsetSyncros - Acros Angle adjust & Cable Routing HS System-0.6° head angle adjustmentZS56/28.6 – ZS56/40 MTB
Hub (Front)Formula CL-811 / 15x110mm
Hub (Rear)Formula CL-148S / 12x148mm
SpokesStainless Black 15G / 1.8mm
RimsSyncros X-30S / 32H / 30mm / Sleeve Joint
Front TireMaxxis Dissector / 27.5x2.4" / 60TPI FoldableTubeless Ready / EXO
Rear TireMaxxis Dissector / 27.5x2.4" / 60TPI FoldableTubeless Ready / EXO
Approx weight in KG14.7
Approx weight in LBS32.409999999999997
Max. System Weight80 kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
