FRAME
Genius Carbon / IMP Technology / HMF Main Frame, BB92 / Alloy SL 6011 swingarm, VLK Virtual 4 Link kinematic, 27.5" (2.6 & 2.8) and 29" (2.4 & 2.6) tire compatible with Geo-BB adj., SW dropouts for Boost 12x148mm, TBC Trunnion box construction
FORK
FOX 36 Float Performance Air Grip 3, 3-Modes / Kabolt 15x110mm axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 150mm travel
REAR SHOCK
FOX NUDE T EVOL Trunnion SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, custom large air volume / DPS / Reb. Adj., Travel 150-100-Lockout / 185X55mm
REMOTE SYSTEM
SCOTT TwinLoc TSP Technology Suspension-Seatpost Remote, below Bar / 3 modes / integ. Grip clamp
REAR DERAILLEUR
Shimano XT RD-M8100 SGS, Shadow Plus / 12 Speed
SHIFTERS
Shimano Deore SL-M6100-IR / Rapidfire Plus Ispec EV clamp
CRANKSET
Shimano SLX FC-M7100-1 / Hollowtech 2, 32T
CHAINGUIDE
SCOTT custom
BB-SET
Shimano BB-MT500 / shell 41x92mm
CHAIN
Shimano Deore CN-M6100
CASSETTE
Shimano Deore CS-M6100-12 / 10-51 T
BRAKES
Shimano Deore M6120 4 Piston Disc
ROTOR
Shimano SM-RT66 / 6 Bolt / 203/F and 180/R
HANDLEBAR
Syncros Hixon 1.5 / Alloy 7050D.B., 12mm rise / 9° / 780mm, Syncros Pro lock-on grips
H'STEM
Syncros FL1.5 / Alloy 2014, integrated Spacer & Top Cap / 31.8mm / 6° / 1 1/8"
SEATPOST
Syncros Duncan Dropper Post 2.0, 31.6mm / S size 100mm / M size 125mm / L & XL size 150mm
SEAT
Syncros Tofino 2.0 Regular, CRMO rails
HEADSET
Syncros Pro Press Fit E2 / Tapered 1.5"-1 1/8", OD 50/62mm / ID 44/56mm
WHEELSET
Syncros Revelstoke 2.5 6 Bolt, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready rim 28H / Micro Spline, Syncros Axle w/Removable Lever with Tool
FRONT TIRE
Maxxis Dissector / 2.6" / 60TPI Foldable, Tubeless Ready / EXO 3C maxx Terra
REAR TIRE
Maxxis Rekon / 2.6" / 60TPI Foldable, Tubeless Ready / EXO 3C maxx Terra
EXTRAS
Fox 36 Fender
APPROX WEIGHTS IN KG
14.20 (with tubes)
APPROX WEIGHTS IN LBS
31.31 (with tubes)
MAX. SYSTEM WEIGHT
128 kg
