FRAME
Alloy Frame / Virtual 4 link kinematic VLK, 27.5" and 29" compatible / geo adj. / Boost 148x12mm, 140mm travel / Bosch Gen4 / Integr. removable Battery, Tapered Headtube E2, Central Kickstand Mount, Range Booster Ready
TRAVEL
Front: 140mm / Rear: 140mm
FORK
Marzocchi Z2 Air / eMTB+, Rail 3 / 3-Modes / 15x110mm QR axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 140mm travel
REAR SHOCK
X-Fusion NUDE Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Reb. Adj., Travel 140-90-Lockout / 185x50mm
REMOTE SYSTEM
SCOTT TwinLoc 2 Technology, Suspension & Dropper Remote, 3 modes
DRIVE UNIT
Bosch Performance CX, EU: 25kmh / INT: 20mph
BATTERY
PowerTube 625Wh
DISPLAY
Bosch Purion
CHARGE
4A Charger
REAR DERAILLEUR
SRAM NX Eagle / 12 Speed
SHIFTERS
SRAM SX Eagle Single Click
CRANKSET
FSA CK-320 / 165mm / 34T
CHAINRING
SRAM Eagle 34T DM / Steel
CHAIN
SRAM SX Eagle
CASSETTE
SRAM PG1210 / 11-50 T
BRAKES
SRAM DB8 4 Piston Disc
ROTOR
Centerline CL Rotors 200mm F&R
HANDLEBAR
Syncros Hixon 2.0 Rise / Alloy 6061D.B., 20mm rise / 8° / 760mm, Syncros Comfort lock-on grips
H'STEM
Syncros FL2.0 / 6061 Alloy, L-Shape Spacer & Top Cap / 31.8mm / 6° / 1 1/8"
SEATPOST
Syncros Duncan Dropper Post 2.5, 31.6mm / S size 100mm / M size 125mm / L size 150mm / XL size 170mm
SEAT
Syncros Capilano
HEADSET
Syncros ER2.0 Press Fit E2 / Tapered 1.5"-1 1/8", OD 52/62mm / ID 44/56mm
HUB (FRONT)
Formula CL-811 / 15x110mm
HUB (REAR)
Formula CL-148S / Boost 148x12mm
SPOKES
Stainless Black
RIMS
Syncros MD30 / 32H / 30mm / Pin Joint, Tubeless ready
FRONT TIRE
Maxxis Rekon / 29x2.6" / 60TPI Wire Bead, EXO, Dual
REAR TIRE
Maxxis Rekon / 29x2.6" / 60TPI Wire Bead, EXO, Dual
LIGHTS
Bosch Light Cable pre-installed F&R
APPROX WEIGHTS IN KG
24.3 (with tubes)
APPROX WEIGHTS IN LBS
53.57 (with tubes)
MAX. SYSTEM WEIGHT
128kg, The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
