SUPER POWERFUL AND DYNAMIC E-MOTOR
The efficient Bosch Performance CX e-drive (Gen. 4) supports your ride up to 25 km/h with powerful 85 Nm. The strongest e-motor of Bosch is perfectly integrated, the JAM² rides agile and nimble. In eMTB mode, the motor support adjusts automatically to your riding power.MORE TRAILS
The Bosch Powertube battery is perfectly integrated into the down tube, yet it can also be removed at any time for charging. For sure, you can also charge it directly on the bike. Thanks to 625 Wh battery capacity, you can ride all your trails again and again.OPTIMAL SUSPENSION PERFORMANCE IN ANY SITUATION
Our F.O.L.D. chassis has been specially designed to meet the increased demands placed on e-MTBs. This means that we can also guarantee the perfect mix for the e-All-Mountain JAM²: F.O.L.D. is extremely sensitive while being progressive enough to prevent a harsh bottom out.
FRAME MATERIAL: Aluminium
FRAME:7005 hydroformed aluminium, 3D forging, 150 mm F.O.L.D. kinematic, 148x12 mm thru axle, internal cable routing, post mount 203 mm
FORK: Rock Shox Recon RL 29 Boost, E-MTB, 110x15 mm, 51 mm rake, 150 mm travel
TRAVEL FORK: 150 mm
SHOCK: RockShox Deluxe Select, 210/55 mm, hardware: 25,0 x 8mm, custom tune
MOTOR: Bosch Performance CX Gen4, 85 Nm, 250 W
BATTERY WATT-HOURS: 625 Wh
BATTERY AMPERE HOURS: 16,7 Ah
DISPLAY: Bosch Purion
SHIFTER: Shimano SLX M7100, 12-speed
REAR DERAILLEUR:
Shimano SLX M7100, 12-speed
SPROCKET
Shimano SLX M7100, 12-speed
CHAIN
Shimano SLX CN-M7100
CRANKSET
FSA CK-320, aluminium
TRANSMISSION OF DRIVE
front: 34, rear: 10-51
BOTTOM BRACKET
Integraded in Drive Unit
HANDLEBAR
BBB Ascension BHB-110, aluminium, riserbar, 780mm, rise: 20mm, backsweep: 9degree
GRIPS
FOCUS Locker SL
STEM
BBB Jumper BHS-138, 31.8 mm
HEADSET
VP Components, ZS56/28,6-ZS56/40
SADDLE
FOCUS Trail SL
SEATPOST
Kind Shock E30i, 31,6mm
BRAKES
Shimano BR-MT520, 4 piston
BRAKE LEVER DESCRIPTION
Shimano BR-MT520
BRAKE
Disc
RIMS
RaceFace AR30 Offset
REAR HUB
Novatec D162 Disc, 12x148 mm
FRONT HUB
Novatec D041, 15x110 mm thru axle
TIRES
Maxxis Minion DHF 2.6 Dual EXO TR
REAR TIRE
Maxxis Rekon 2.6 Dual Exo TR
GEARS
12
BIKE WEIGHT INCL. BATTERY IN KG.
23,50 kg
SIZE
49,40,42,45
* Subject to technical modification without notice. Errors and omissions excepted.** Weight in size M, of standard specification and without pedals.
