FRAME
Aluminium Superlite, Gravity Casting, Agile Ride Geometry, 1.5 Headtube, Boost 148, Full Integrated Battery, Advanced Internal Cable Routing, Kickstand/Fender/Carrier Mounting Points
SIZE
Size Split: 27.5: S (15") // 29": M (17"), L (19"), XL (21"), XXL (23"); Easy Entry: 27.5: S (16"), M (18"), L (20"), XL (22")
SUSPENSION FORK
Fox 34 Float AWL, 2-Position Sweep-Adjust RAIL Damper, Tapered, 15x110mm, E-Bike Optimized, 120mm
DRIVE UNIT
Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt), Smart System
BATTERY
Bosch PowerTube 750
REMOTE
Bosch LED Remote
DISPLAY
Bosch Kiox 300
CHARGER
Bosch 4A
BRAKE SYSTEM
Shimano XT BR-M8120, Hydr. Disc Brake (203/203)
REAR DERAILLEUR
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
SHIFTERS
Shimano XT SL-M8100-IR, Direct Attach
CRANKSET
ACID MTB Hybrid Pro Crank, 38T, 175mm
CASSETTE
Shimano Deore CS-M6100, 10-51T
CHAIN
Shimano CN-M6100
HANDLEBAR
CUBE Rise Trail Bar Pro, 740mm
STEM
CUBE Performance Stem E-MTB, 31.8mm
GRIPS
ACID React Pro / EE: ACID Hybrid Perform
HEADSET
ACROS AZF-1035, ICR (Integrated Cable Routing), BlockLock 120°, Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm)
WHEELSET
Newmen Performance 30, 28/28 Spokes, 15x110mm/12x148mm, Tubeless Ready
TYRES
Schwalbe Smart Sam, Performance, Double Defense, 2.6, Next Gen
SEAT POST
CUBE Performance Post, 30.9mm
SADDLE
Natural Fit Sequence
PEDALS
ACID PP MTB
WEIGHT
23,8 kg
