NEWRider Fit GeometryRedistributed sizing based around Stack and Reach measurements, with semi sloping frame on the smallest frames. This not only reduces the stand over height but also brings comfort in line with our larger models.
NEWCarbon ForkIncreased tyre, mudguard clearance and mounting point for a dynamo lamp.
NEWRevised BB ShellIncreased internal space to allow the use of 30mm axle cranks with Di2 internal routing.
NEWImproved Cable RoutingProvisions for full gear outer cable from the shifter to the rear derailleur. This protects against water and dirt ingress, preserving shifting performance for longer.
Curved seat stays
Maximises rear end compliance for vibration damping, whilst the straight chain stays stiffen the frame laterally for maximum power transfer.
12mm Thru Axle Front and Rear
Industry standard for maximum wheel security and bike stiffness. With a removable GW Switch Lever, giving a clean, elegant look.
Adaptable Cable Ports
Versatility with set up choice for any major groupset.
Abundance of mounts
Bottle mounts, rack mounts, mudguard mounts, for versatile all seasons riding.
Thru Axle Located Derailleur Hanger
Thru Axle locates through the hanger for maximum hanger rigidity, with no negative effect on deformation during impact.
Custom CNC dropouts
With discreet Di2 routing.
Frame Weight:
XXS (48cm ) - 1.63kg.
XS (50cm) - 1.66kg.
SM (52cm) - 1.70kg.
MD (54cm) - 1.74kg.
LG (56cm) - 1.79kg.
XL (58cm) - 1.84kg.
XXL (60cm) - 1.89kg.
